Diesel pellet mill is developed to conduct a small scale production. In consideration of various situations of different places, Diesel pellet making machines are designed to work with a diesel engine. So you are not necessary to wire, but just to add some diesel oil to make the press keep running. And the flexible and moveable body can be placed freely for processing.
Technical Data of Diesel Pellet Mill
Model
Power
Capacity
Weight（NW/GW）
Packing Size
ZLSP200A
15 HP
80-120kg/h
320/350kg
1460*950*1100mm
170-270lbs/h
705/772lbs
58*37*55inch
ZLSP300A
36 HP
250-350kg/h
850/890kg
1100*700*2480mm
550-770lbs/h
1874/1962lbs
43*28*98 inch
ZLSP400A
55 HP
350-450 kg/h
1010/1050kg
1300*800*2600mm
770-990 lbs/h
2227/2315lbs
51*31*102 inch
Working Principle of Diesel Pellet Mill
Diesel pellet mill developed by GEMCO adopts the flat die design. It works by the compression between main components of rollers and die--the bearings in the gear box will drive them to rotate and produce a great force in the pelletizing room, and materials inside will be pushed into holes on the die. A knife beside the edge will cut those pressed granule to uniform size. When they get out of this place, pellets are finished.
Operate of Making Pellets by Diesel Pellet Mill
Application of Diesel Pellet Mill
Diesel driven small pellet press is famous for its convenience. At the same time, the wide scope of raw material also makes this machine widely employed. Family users, especially those who have farms or orchards, can use this pellet press with diesel engine to process pellets when do harvesting. Furniture manufacturers can also apply such a machine to turn the annoying sawdust and useless wood scraps into pellets and sell them to local district. A diesel pellet mill is also available for those who want to process pellet in small scale.
Why Choose Our Diesel Pellet Mill?
Quality is ensured.
Each machine produced must be examined strictly by our professional quality department.
Durability is enhanced with the employment of alloy steel.
The intensity, thickness, length, etc are strictly standardized
CE and ISO9001 certified.
Usage life is prolonged.
Finished diesel pellet mill will be sent into our special paint workshop. After painting, each machine will be sealed to avoid the accumulation of dust and rusting.
Both sides of the die can be used.
Performance is excellent.
High efficient, high productivity, low cost and low energy consumption.
Diameter of pellets is adjustable with changing dies.
